BMS Solution

Overview Solution Block Diagram Customer and Cooperation Case

Based on the BMS solution of E3 MCU The solution is characterized by
● Up to 3 independently programmable 600MHz R5 cores
● 3MB large capacity SRAM
● Three independent 4MB large capacity SRAM cores and 48 analog channels
● Two gigabit Ethernet, multichannel CAN-FD, SPI and LIN
● Single 3.3V power supply or equipped with SBC/PMIC power supply

Customer Value
● Monitor the state of more cells in an accurate way, maximize the whole package of available battery capacity and improve the economic benefits.
● Support the functional safety design of ASIL - D level BMS system, and carry out safety monitoring on sampling, communication and cell temperature to guarantee the reliability and security of the system.

Solution Block Diagram
