ZCU Solution

Overview Solution Block Diagram Customer and Cooperation Case

Based on the ZCU solution of E3 MCU The solution is characterized by
● Up to 5 independently programmable 600MHz R5 cores
● 4MB large capacity SRAM
● 8 SPI modules and each module has four chip selection signals
● Two gigabit Ethernet, multichannel CAN-FD and LIN
● Single 3.3V power supply or equipped with SBC/PMIC power supply

Customer Value
● Rich CAN and LIN nodes used to connect sensors and actuators
● Support ASIL - D level system functional safety design
● Use the dual-channel gigabit Ethernet TSN as the backbone network of ECU
● With high computing power and large storage, it can support the integration of more multi-functions.

Solution Block Diagram
